Use solvent

• Hydrocarbon solvents (carbonized hydrogen), modified alcohols, or other
  non-aqueous organic solvents.

Cleaning process

• Process 1：Ultrasonic cleaning 1→Ultrasonic cleaning 2→Cleaning liquid spray→
  Steam shower→Vacuum drying​

• Process 2：Ultrasonic cleaning 1→clean liquid spray cleaning→steam shower→
  vacuum drying

• Process 3：Steam shower→clean liquid spray→vacuum drying

• ※CH-HOCV series single-chamber automatic vacuum cleaning machine can plan
  different cleaning processes according to needs.

Cycle time

• 20~50min/basket (the process is different from the cleaning weight, and the
  cleaning cycle time is different)

Loss of lotion

• ＜100ml/basket

• >180L/hr (based on hydrocarbon solvents)

• Manual / automatic (optional)

Loading capability

• 100~800kg

Rotating mechanism

• Optional

Equipment Specifications

• Customized cleaning equipment.

• The CH-HOCV series automatic cleaning machine operates in a closed vacuum
  environment, which is safe, explosion-proof, energy-saving and emission-reducing,and consumes less detergent.

• The air emission of this vacuum cleaner is far lower than the VOC standard, in line with ROHS or any other environmental protection regulations.

• Various cleaning programs can be set for different parts.

• The cleaning and drying machine is in place without changing the tank.

• The basket has a rotating mechanism to make cleaning more complete and without cleaning blind spots (CH-HOCV-R series).

• No oxidation occurs after cleaning.

• The problem of zero wastewater discharge.
