Product
description

• Vacuum deaerator：Generally, non-aqueous lotion is used. Due to the amount of air dissolved in the lotion, the strength of the ultrasonic wave cannot be used normally. Therefore, a vacuum deaerator is needed to remove the air dissolved in the lotion. Extraction, in order to strengthen the ultrasonic effect, enhance the cleaning efficiency, and get a double cleaning effect.

Suitable

• All cleaning solvents with poor ultrasonic effect can be installed.

model

• CH-VD-25

way to control

• PLC

• >220V/380V*3Ø*0.5kw

• 5-7kg/cm2

Dimensions

• 2450*700*1450mm

Cavity material

• SUS304

Cavity capacity

• 25L

　   There is no effect on the
　　surface of tin-foil after
　　placing into ultrasonic tank

       Surface of tin foil is severe
  　damaged after-placing into
  　 degassing ultrasonic tank
